OpenAstro Linux v1.0

joeytroy released this 26 Apr 06:06

· 43 commits to master since this release

7446300

OpenAstro Linux v1.0 — Debian 13 Trixie for ASIAIR Plus

Replace the stock ZWO firmware on your ASIAIR Plus RockChip with Debian 13 (Trixie). Restore to stock at any time from your backup.

What's in the image

Debian 13 (Trixie) arm64 rootfs — clean minimal install
Stock kernel 4.19.219 — the same Rockchip BSP kernel that ships with your ASIAIR
Stock firmware — BCM43456 WiFi/Bluetooth, all hardware drivers
Stock boot chain untouched — only partition 7 (rootfs) is replaced

Image Details


File	`astrolinux-trixie-rk3568.img.gz`
Target	ASIAIR Plus 256GB (RK3568)
Partition	p7 — rootfs (sector 0x1BD38000)
Filesystem	ext4, 4 GB
Kernel	Linux 4.19.219 (stock, not modified)
Hostname	`astro`
User	`astro` / `astro`
Root	`root` / `astro`
SSH	Enabled (password auth)
WiFi	Configure via `nmcli`
Networking	NetworkManager

What works

WiFi (BCM43456) and Bluetooth
All 4 USB ports
12V DC power input
LEDs and GPIO (pwm_gpio auto-loaded)
SSH out of the box
Swap on p8

Assets 3
