Remote Tool Calling — Integrate AI Assistant into Your Website with 3 Lines of Code

Not screenshot recognition, not DOM crawling. AI operates websites directly through frontend tools — every step transparent and observable.

---

One-liner: An open-source website AI assistant backend. Integrate a transparent, efficient, and cost-effective AI assistant into your website with just a few lines of code via the standardized Remote Tool Calling protocol.

RTC Agent lets AI reason on the server while tools execute on the frontend — reading page content, operating a virtual file system, calling business APIs — all synchronized in real-time over WebSocket, fully visible to your users.

🎯 Who Should Use RTC Agent?

• SaaS product teams: Want to add an AI assistant to their product without restructuring the backend
• Frontend developers: Want to quickly integrate AI capabilities, focusing on business logic rather than AI infrastructure
• Privacy-sensitive applications: Healthcare, finance, enterprise internal tools — where data cannot leave the user's device

---

✨ Core Capabilities

📂 Frontend Virtual File System

Built on IndexedDB, AI tools (read / write / ls / grep) operate directly on frontend files. Data never leaves the user's browser.

🔑 Script Tool + Function Composition

Developers only need to maintain their own Function library. The Agent executes them on the frontend via the script tool and can freely combine multiple Functions to accomplish complex tasks — no predefined workflows needed.

💡 Developer's perspective: You just define your business atomic capabilities (Functions), and the Agent learns how to combine them on its own. It's like giving AI a set of LEGO bricks — it figures out how to build what you want.

💬 Real-Time Communication

Built on Centrifuge WebSocket, with bidirectional message pushing, supporting streaming output, tool call progress, and state synchronization.

🧠 Memory System

Dual-layer memory: Session Memory (conversation context compression) + User Memory (cross-session long-term memory with vector retrieval). AI truly "remembers" your users.

🗜️ Context Management

Automatically compresses long conversations, keeping token consumption under control. Say goodbye to "context length exceeded" errors.

🤖 Sub-Agents + 🎯 Goal-Driven Execution

Complex tasks are automatically decomposed, with multiple specialized sub-agents working in parallel. AI sets, tracks, and completes multi-step goals, with turn-boundary checkpoints ensuring no task is lost.

---

🏗️ Architecture

flowchart LR
    subgraph BROWSER["🖥️ Browser / Frontend"]
        direction TB
        UI["👤 Web Component"]
        WS["🔌 WebSocket Client"]
        SCRIPT["🔑 script tool"]
        TOOLS["⚙️ Basic Tools"]
        VFS[("💾 Virtual File System<br/>IndexedDB")]
        FX["📦 Function Library"]
    end

    subgraph SERVER["⚙️ RTC Agent Server"]
        direction TB
        GW["🌐 WebSocket Gateway"]
        AUTH["🔐 Auth"]
        CTX["🗜️ Context Manager"]
        MEM["🧠 Memory System"]
        AGENT["🤖 Agent Engine"]
    end

    LLM["🧠 LLM Provider"]

    UI -->|User message| GW
    GW --> AUTH --> CTX
    CTX -.->|Inject memory| MEM
    CTX --> AGENT
    AGENT -->|Inference request| LLM
    LLM -->|tool_calls| AGENT
    AGENT -->|script call| GW
    GW <-->|WebSocket| WS
    WS --> SCRIPT
    WS --> TOOLS
    SCRIPT -->|Compose calls| FX
    SCRIPT -->|Read/Write| VFS
    TOOLS -->|Read/Write| VFS
    SCRIPT -->|Results| WS
    AGENT -->|Response| GW
    GW -->|Streaming output| UI

    style BROWSER fill:#e1f5fe,stroke:#0288d1,stroke-width:3px
    style SERVER fill:#f3e5f5,stroke:#7b1fa2,stroke-width:3px
    style LLM fill:#fff3e0,stroke:#f57c00,stroke-width:2px
    style VFS fill:#c8e6c9,stroke:#388e3c,stroke-width:2px
    style SCRIPT fill:#ffeb3b,stroke:#f9a825,stroke-width:2px,color:#000

Loading

Core data flow:

1. All Function and file data live in the browser's IndexedDB — the server never touches business data
2. The Agent Engine sends tool calls to the browser via the RTC protocol; the browser executes and returns results
3. Memory and context management run on the server, optimizing conversation quality

---

🔄 How It Works

sequenceDiagram
    participant U as User
    participant FE as Frontend
    participant S as Server
    participant LLM as LLM Provider

    U->>FE: Send message
    FE->>S: WebSocket push
    S->>S: Inject memory, compress context, load Function manifest
    S->>LLM: Inference request
    LLM-->>S: tool_calls (request to call Functions)
    S->>FE: RTC event (tool call request)
    FE->>FE: script tool executes Function
    FE->>S: Submit execution result
    S->>LLM: Continue reasoning with result
    LLM-->>S: Final response
    S->>FE: Streaming output
    FE->>U: Display result

Loading

🔑 Key Differences

	Traditional Approach	RTC	RTC + Function
Tool execution location	Server-side ❌	Frontend ✅	Frontend ✅
Data flow	Uploaded to cloud 🔒	Stays on user device 🔐	Stays on user device 🔐
Extension method	Modify server code	Define frontend tools	Just define Functions; the Agent learns to compose them

---

📊 Comparison with Other AI Assistant Solutions

Solution	Integration Cost	Observability	Token Cost	Error Rate	Privacy & Security
RTC Agent	Low — a few lines of code	Fully transparent	Low	Low	Data stays on frontend
Visual Parsing (Screenshot + OCR)	Medium	Black box	Very high	Relatively high	Requires uploading screenshots
DOM Crawling (Server-side parsing)	Complex	Partially visible	Medium	Medium	Data uploaded to cloud
Browser Extension	Requires installation	Good	Medium	Medium	Runs locally

Every solution has its place: visual parsing works well for legacy systems with zero modification, and browser extensions suit offline scenarios. RTC Agent's advantage is — no installation, no screenshots, no server-side changes — just a few lines of code to let AI understand and operate your website in a structured way.

---

🚀 Next Steps

• Getting Started — Integrate RTC Agent in 5 minutes
• Core Concepts — Deep dive into the RTC protocol and virtual file system
• Integration Guide — Learn how to register Functions and write Scenarios

---
