Backend Bridge Configuration

The backend bridge is optional. Install it when you want a Java inventory selector or when a backend should announce itself through Redis. Velocity still makes every routing decision.

Install and verify

1. Put the same VelocityNavigator-4.3.0.jar on the Velocity proxy and the backend's plugins/ directory.
2. Start the backend once to create plugins/VelocityNavigator/config.yml.
3. Join that backend through the proxy once.
4. On the proxy, run /vn bridge status and confirm the backend is listed.

The backend must run Java 17 or newer. The bridge is built against the Spigot 1.16.5 API and uses no version-specific NMS.

Core settings

enabled: true
inventory_menu_enabled: true
handshake_enabled: true
refresh_enabled: true
handshake_delay_ticks: 20
max_title_length: 32
fallback_material: COMPASS

Key	Default	Meaning
enabled	true	Enables the backend bridge. Disable it when this backend never renders the Java selector.
inventory_menu_enabled	true	Allows the proxy to open inventory menus on this backend.
handshake_enabled	true	Reports bridge availability to the proxy; leave enabled for /vn bridge status.
refresh_enabled	true	Accepts menu refresh and page-navigation messages.
handshake_delay_ticks	20	Delay before the bridge announces itself after a player joins.
max_title_length	32	Maximum inventory title length accepted by the bridge.
fallback_material	COMPASS	Material used when a requested menu material is unavailable.

The Velocity-side routing.use_menu_for_lobby, routing.java_menu.type, and routing.java_menu.fallback_to_chat settings decide whether a player is offered the inventory selector. gui.toml on the proxy controls layout, slot overrides, icons, and refresh timing.

Which files belong on which server

The universal JAR runs in two modes, but its configuration is not shared automatically:

Location	Files to edit
Velocity proxy	plugins/velocitynavigator/navigator.toml, messages.toml, gui.toml, and servers.toml
Paper or Spigot backend	plugins/VelocityNavigator/config.yml

Keep menu text, colors, rows, icons, and per-server slot overrides on the proxy. The backend's config.yml only controls bridge safety limits, the handshake, backend telemetry, and optional Redis registration. Do not copy navigator.toml or gui.toml into a backend plugin folder; the bridge does not read them.

Backend telemetry

bstats_enabled: true
bstats_plugin_id: 0

Backend telemetry is independent from the Velocity bStats project. Set bstats_plugin_id to the official Bukkit/Spigot project ID only after it is assigned. Leave it at 0, or set bstats_enabled: false, to disable backend telemetry.

Optional Redis registration

redis:
  enabled: false
  host: 127.0.0.1
  port: 6379
  username: ''
  password: ''
  ssl: false
  channel_prefix: vn
  connect_timeout_ms: 3000
  read_timeout_ms: 10000
  registration_secret: ''
  server_name: ''
  advertised_host: ''
  advertised_port: 0
  group: default
  max_players: -1
  weight: 1
  unregister_on_shutdown: true

Set enabled: true only when the Velocity proxy also enables Redis. registration_secret must exactly match the proxy’s secret. server_name must be unique; advertised_host must be reachable by every proxy and permitted by each proxy’s allowed_registration_hosts. An advertised_port of 0 uses the Bukkit server port.

Keep Redis private, use TLS outside trusted networks, and configure both a secret and allowlist on every proxy. Redis registration is runtime-only; use /vn server add lobby when the server must also be written to velocity.toml and servers.toml.

Troubleshooting

• Chat fallback opens: confirm this backend has the JAR, a player has visited it, and /vn bridge status sees it.
• Menu opens but clicks do nothing: allow the velocitynavigator:menu plugin channel and keep the player on the backend that opened the menu.
• Redis registration is rejected: compare secret, timestamp, host allowlist, advertised host/port, and server name; run /vn redis status and /vn redis test on the proxy.
• Material/title problems: use the proxy’s gui.toml; the bridge applies fallback_material and max_title_length only as safe backend limits.
