Contextual Routing Guide

Contextual Routing Guide

Contextual routing keeps each game mode connected to its own lobby pool. A player leaving BedWars can return to a BedWars lobby, while a SkyWars player goes back to SkyWars, without needing separate lobby commands.

What Is Contextual Routing?

By default, all players who type /lobby are routed from the same global pool (default_lobbies). On a network with multiple game modes, you often want players to return to a game-specific lobby rather than a generic hub.

Contextual routing lets you define groups of lobbies and map source servers to those groups. When a player leaves bedwars-1 and types /lobby, they are routed to the BedWars lobby pool instead of the generic one.

---

When to Use It

• You have game-mode-specific lobbies (BedWars hub, SkyWars hub, etc.).
• You want players to stay in a game-mode ecosystem when they finish a match.
• Different game modes need different routing algorithms.
• You want fallback chains so players always have somewhere to go.

---

Basic Setup

Step 1: Define Your Groups

Each group is a named collection of lobby servers:

[routing.contextual.groups.bedwars_lobbies]
servers = ["bw-hub-1", "bw-hub-2"]

[routing.contextual.groups.skywars_lobbies]
servers = ["sw-hub-1", "sw-hub-2"]

[routing.contextual.groups.main_hubs]
servers = ["hub-1", "hub-2", "hub-3"]

Step 2: Map Source Servers to Groups

When a player leaves a source server and uses /lobby, they are routed to the mapped group:

[routing.contextual.sources]
"bedwars-1" = "bedwars_lobbies"
"bedwars-2" = "bedwars_lobbies"
"skywars-1" = "skywars_lobbies"
"skywars-2" = "skywars_lobbies"

Step 3: Enable It

[routing.contextual]
enabled = true
fallback_to_default = true

That is the basics. Players leaving BedWars servers are now routed to BedWars lobbies.

---

Per-Group Selection Mode Override

Each group can override the global selection_mode. For example, you might want BedWars lobbies to use consistent_hash (so players return to the same lobby they were on) while other groups use the global mode:

[routing.contextual.groups.bedwars_lobbies]
servers = ["bw-hub-1", "bw-hub-2"]
mode = "consistent_hash"

[routing.contextual.groups.skywars_lobbies]
servers = ["sw-hub-1", "sw-hub-2"]
mode = "power_of_two"
# If mode is omitted, the global selection_mode is used

Useful pairings:

• consistent_hash for groups where you want players to return to the same lobby (inventory cache, party reconnection).
• power_of_two for high-traffic groups that need fast, even distribution.
• weighted_round_robin for groups with servers of different capacities.

---

Fallback Chain Configuration

When all servers in a group are down, the fallback chain determines the ordered list of groups to try next:

[routing.contextual.fallback_chain]
bedwars_lobbies = ["main_hubs", "skywars_lobbies"]
skywars_lobbies = ["main_hubs"]

How it works:

1. Player leaves bedwars-1 → maps to bedwars_lobbies.
2. All BedWars lobbies are down → check the fallback chain.
3. Try main_hubs → hub-2 is healthy → route there.

If no fallback group has available servers and fallback_to_default = true, the default lobby pool is used as a last resort.

---

Using LobbyEntry with Groups

Groups support the same LobbyEntry format as default_lobbies:

[routing.contextual.groups.bedwars_lobbies]
servers = [
  { server = "bw-hub-1", max_players = 80, weight = 3 },
  { server = "bw-hub-2", max_players = 40, weight = 1 },
]
mode = "weighted_round_robin"

This lets you:

• Set max_players per server in a group (smaller servers receive fewer players).
• Set weight for weighted round-robin distribution.
• Mix plain strings and inline tables.

---

Real-World Examples

Example 1: PvP Network

A network with duels, FFA, and a main hub:

[routing.contextual]
enabled = true
fallback_to_default = true

[routing.contextual.groups.duel_lobbies]
servers = ["duel-hub-1", "duel-hub-2"]
mode = "consistent_hash"  # Players return to their duel hub

[routing.contextual.groups.ffa_lobbies]
servers = [
  { server = "ffa-hub-1", max_players = 200 },
  { server = "ffa-hub-2", max_players = 200 },
]
mode = "power_of_two"

[routing.contextual.sources]
"duel-1" = "duel_lobbies"
"duel-2" = "duel_lobbies"
"ffa-1" = "ffa_lobbies"
"ffa-2" = "ffa_lobbies"

[routing.contextual.fallback_chain]
duel_lobbies = ["ffa_lobbies"]
ffa_lobbies = ["duel_lobbies"]

Example 2: Event Network

A network that runs events with a special event lobby:

[routing.contextual]
enabled = true
fallback_to_default = true

[routing.contextual.groups.event_lobbies]
servers = ["event-hub"]
mode = "round_robin"  # Only one server, doesn't matter

[routing.contextual.groups.main_hubs]
servers = ["hub-1", "hub-2", "hub-3"]
mode = "least_players"

[routing.contextual.sources]
"event-1" = "event_lobbies"
"event-2" = "event_lobbies"

[routing.contextual.fallback_chain]
event_lobbies = ["main_hubs"]

Example 3: Mixed Network with Weighted Servers

A network where some lobby servers are larger than others:

[routing.contextual]
enabled = true
fallback_to_default = true

[routing.contextual.groups.priority_lobbies]
servers = [
  { server = "priority-hub-1", max_players = 500, weight = 5 },
  { server = "priority-hub-2", max_players = 300, weight = 3 },
]
mode = "weighted_round_robin"

[routing.contextual.groups.standard_lobbies]
servers = [
  { server = "std-hub-1", max_players = 100, weight = 2 },
  { server = "std-hub-2", max_players = 100, weight = 2 },
  { server = "std-hub-3", max_players = 100, weight = 1 },
]
mode = "power_of_two"

[routing.contextual.sources]
"priority-game-1" = "priority_lobbies"
"standard-game-1" = "standard_lobbies"
"standard-game-2" = "standard_lobbies"

---

Troubleshooting Contextual Routing

Symptom	Likely Cause	Fix
Players always go to default lobbies	enabled = false	Set enabled = true in [routing.contextual]
Player from game server goes to wrong lobby	Source server not in sources map	Add the source server name (must match velocity.toml exactly)
"No lobby found" error	All group lobbies offline, fallback_to_default = false	Set fallback_to_default = true or add a fallback chain
Fallback chain not working	Chain references group name that doesn't exist	Verify group names match exactly
