Migration Guide v3 to v4

Migration Guide: v3 → v4

The upgrade is straightforward, but keep a copy of the old plugin folder until you have tried the new JAR on one proxy. This guide walks through the files and settings worth checking.

Before You Begin

Back up your config before starting.

cp plugins/velocitynavigator/navigator.toml plugins/velocitynavigator/navigator.toml.v3-backup

Also back up your entire plugins/velocitynavigator/ directory if you want to be safe.

---

Step 1: Replace the JAR

1. Download VelocityNavigator-4.3.0.jar from the VelocityNavigator Modrinth page.
2. Remove the old JAR from plugins/.
3. Place the new JAR in plugins/.

plugins/
├── VelocityNavigator-4.3.0.jar   ← new
└── velocitynavigator/
    ├── navigator.toml              ← will be auto-migrated
    └── ...

---

Step 2: Start the Proxy

Start (or restart) your Velocity proxy. VelocityNavigator v4 will:

1. Detect the v3 config format.
2. Automatically migrate it to v4 format.
3. Create a backup at navigator.toml.bak.
4. Log any migration warnings to the console.

You should see something like:

[VelocityNavigator] Config migrated from v3 to v4 format. Backup saved as navigator.toml.bak

---

Step 3: Verify the Migration

Compare the backup with the new config

diff plugins/velocitynavigator/navigator.toml.bak plugins/velocitynavigator/navigator.toml

Check for logged warnings

Review the proxy console for any warnings like:

[VelocityNavigator] WARNING: Config field 'update_checker.enabled' is no longer supported in v4. The update checker now always runs on startup.

These warnings indicate fields that were removed or renamed. See the Config Changes Table below.

Verify routing works

1. Run /vn status to confirm the plugin loaded correctly.
2. Type /lobby in-game to test routing.
3. Run /vn debug player <name> to verify routing decisions.

---

Step 4: Update Scripts and Automation

If you have any scripts or external tools that depend on v3 config fields, update them:

• Scripts reading update_checker.enabled → removed (checker always runs on startup).
• Scripts reading update_checker.notifyConsole → removed (always logs to console).
• Scripts reading update_checker.startupDelaySeconds → removed (fixed at 5 seconds).
• Scripts checking velocitynavigator.bypasscooldown permission → update to velocitynavigator.bypass.cooldown (legacy name still works).

---

Config Changes Table

Removed Fields

Field	Was (v3)	Notes
update_checker.enabled	true/false	Checker now always runs once on startup. Use notifyOnStartup to suppress notification.
update_checker.notifyConsole	true/false	Always logs to console now.
update_checker.startupDelaySeconds	5	Fixed at 5 seconds.

Added Fields

Field	Default	Description
routing.max_retries	2	Connection retry attempts on failure.
circuit_breaker.enabled	true	Enable/disable circuit breaker.
circuit_breaker.failure_threshold	3	Failures before circuit opens.
circuit_breaker.cooldown_seconds	30	Seconds before HALF_OPEN transition.
circuit_breaker.half_open_max_tests	1	Test requests in HALF_OPEN state.
degradation.enabled	true	Enable graceful degradation.
degradation.mode	"random"	Degradation selection mode.
messages.retrying	"<yellow>Connection failed, retrying... (<attempt>/<max>)</yellow>"	Retry notification message.
notify_on_startup	true	Show update notification on proxy start.
notify_admins_on_join	true	Notify admins with velocitynavigator.admin permission about available updates when they join.
Contextual group mode	(inherits global)	Per-group selection mode override.
Contextual fallback_chain	{}	Fallback group ordering.

Changed Fields

Field	v3	v4	Migration
routing.default_lobbies	["lobby-1", "lobby-2"]	Same format + inline tables	Backward compatible — plain strings still work
routing.selection_mode	3 modes	7 modes	Old modes still work; new: power_of_two, weighted_round_robin, least_connections, consistent_hash
routing.contextual.groups	Map<String, List<LobbyEntry>>	Map<String, GroupConfig>	Auto-migrated; GroupConfig adds optional mode field

---

Permission Node Change

v3	v4	Notes
velocitynavigator.bypasscooldown	velocitynavigator.bypass.cooldown	Both still work. The old name is checked as a fallback. Update your permission plugins when convenient.

---

New Commands

Command	Description
/vn drain <server>	Mark a server as drained (no new players routed)
/vn undrain <server>	Remove the drain flag
/vn drain status	List all drained servers
/vn updatecheck	Manually check for updates

---

Rollback

If v4 causes issues, you can roll back:

1. Stop the proxy.
2. Replace the v4 JAR with the v3 JAR.
3. Restore the v3 config:

   cp plugins/velocitynavigator/navigator.toml.v3-backup plugins/velocitynavigator/navigator.toml

4. Start the proxy.

---

v4.1.0 Update: Config Version v5

If upgrading from v4.0.0 to v4.1.0, the config auto-migrates from version 4 to version 5.

New v4.1 Config Sections

[startup]         → Welcome messages
[lobby]           → Empty lobby strategy (disconnect / fallback_server)
[bedrock]         → Bedrock/Geyser player support

New v4.1 Config Keys

• messages.formatting — legacy color conversion mode (auto, minimessage, legacy)
• messages.dashboard_healthy / dashboard_draining / dashboard_open / dashboard_offline — customizable /vn servers status colors
• startup.welcome_enabled — first-run experience. The old startup.wiki_url key is removed automatically because documentation links now always use the official wiki.
• lobby.no_server_strategy / lobby.no_server_message / lobby.fallback_server — empty lobby fallbacks
• bedrock.* — full Bedrock/Geyser configuration block

Permission Default Changed

In v4.1.0, commands.permission defaults to "none" instead of "velocitynavigator.use". Existing configs with a custom permission are preserved during migration.

New Commands

Command	Description
/vn servers	Paginated lobby server status dashboard

---

v4.2.0 Update: Config Version v6

If upgrading to v4.2.0, the config auto-migrates to version 6.

New v4.2 features and configurations

1. Interactive selector menus:
   • Bedrock Form GUI: automatically displays a native Cumulus SimpleForm lobby selector to Geyser players (customizable titles/content/buttons under [bedrock]).
   • Java chat selector: Adventure-formatted click-to-connect chat menu for Java players (customizable headers/formats/tooltips under [routing]).
2. Ping-based routing (latency):
   • New latency routing strategy selects the server with the lowest measured ping.
3. Prometheus monitoring:
   • Embedded metrics exporter serving Prometheus-formatted metrics at /metrics (configured under [metrics.prometheus]).
4. Grafana setup command:
   • /vn setup grafana generates a pre-configured Grafana dashboard JSON file.

New v4.2 Config keys

• routing.use_menu_for_lobby — toggle the configured Java selector. The old use_chat_menu_for_lobby key remains readable.
• bedrock.use_gui_for_lobby — toggle native Form selector for Bedrock players.
• Bedrock Form title/content/button text moved to [menus.bedrock] in messages.toml.
• metrics.prometheus.enabled / port / bind_host — embedded Prometheus server configuration.

---

v4.3.0 Update: Config Version v8

VelocityNavigator 4.3.0 writes config_version = 8. Any older navigator.toml is backed up as navigator.toml.v<old-version>.bak before the normalized v8 file is written.

The migration also separates presentation and managed-server data:

• messages.toml contains language selection and configurable messages.
• gui.toml contains Java inventory and Bedrock form presentation.
• servers.toml contains command-managed lobby metadata.
• Backend Paper/Spigot installations generate their own config.yml.

New v4.3 systems

1. Universal proxy/backend JAR with a paginated Java inventory selector and /vn bridge status.
2. Seven built-in language packs plus custom codes without automatic player-locale detection.
3. Persistent affinity with a ten-minute TTL, periodic disk saves, and restart restore.
4. Retry backoff with jitter, /vn health, and silent update checks.
5. Optional parties and capacity queues with independently configurable commands and permissions.
6. Optional Redis multi-proxy synchronization and signed backend registration.
7. Backend MOTD lifecycle-state routing.
8. Managed game/lobby server commands with dry-run, validation, backups, atomic writes, and rollback.
9. Prometheus metrics and an optional HTML operations dashboard.

New v4.3 configuration sections

• [dashboard]
• [party]
• [queue]
• [redis]
• [backend_states]
• [server_management]
• [routing.java_menu]
• Expanded [bedrock] and [metrics] settings
• update_checker.silent

All advanced systems can remain disabled. Review Advanced Proxy Systems before enabling Redis, queueing, parties, lifecycle states, or managed server writes.

New v4.3 commands

Command	Description
/vn health	Consolidated routing, cache, circuit, affinity, and Redis diagnostics
/vn bridge status	Show detected backend GUI bridges
`/vn redis status	test`
`/vn server add game	lobby ...`
/vn server dry-run ...	Validate a managed server operation without writing files
`/vn server remove	list ...`
/vn config validate	Validate commands, listeners, Redis, queue, and managed files

After migration, run /vn config validate, restart every bridged backend, and use /vn bridge status before enabling the Java inventory selector for players.

---

See also: Configuration Guide | Changelog
