Health Checks and Circuit Breakers

Health Checks and Circuit Breakers

Health checks stop the router from sending players to a backend that cannot answer. The circuit breaker adds recovery control: after repeated failures, it temporarily removes the server and tests it again after a cooldown.

Health checks

[health_checks]
enabled = true
timeout_ms = 2500
cache_seconds = 60

VelocityNavigator pings candidate backends and caches the result briefly. Live Velocity player counts are still used for routing, so a cached ping does not freeze the displayed load.

Circuit breaker

[circuit_breaker]
enabled = true
failure_threshold = 3
cooldown_seconds = 30
half_open_max_tests = 1

The three states are simple:

1. CLOSED — the backend is available for normal routing.
2. OPEN — repeated failures have temporarily removed it.
3. HALF_OPEN — the cooldown ended and a limited recovery check is allowed.

A successful recovery closes the circuit. Another failure opens it again for the next cooldown.

Useful commands

Command	Use
/vn health	Shows aggregate health, circuit, cache, queue, party, Redis, and affinity diagnostics
/vn status	Shows routing distribution and the main runtime settings
/vn servers [page]	Shows per-lobby online, drain, circuit, player, and capacity state
/vn drain <server>	Stops new routing to a server for maintenance
/vn undrain <server>	Returns a drained server to routing
/vn config validate	Checks the health and circuit settings

Drain mode is the right tool for planned maintenance; circuit breakers are for unexpected failures.

Choosing values

The defaults suit most networks. Lower thresholds react faster but may remove a backend during a brief network hiccup. Longer cooldowns reduce repeated connection attempts but delay recovery. Start with the defaults, then adjust only when your logs show a consistent reason.

When Redis is enabled, health snapshots and circuit state are shared across the Velocity proxies.
