Quick Start Guide

Quick Start Guide

This setup uses two lobbies and power_of_two, a good default for most networks. Once it works, you can add menus, contextual groups, parties, queues, or Redis at your own pace.

Step 1: Download and Install

1. Download VelocityNavigator-4.3.0.jar from the VelocityNavigator Modrinth page.
2. Place the JAR in your Velocity proxy's plugins/ folder.
3. Restart the proxy (or run /vn reload if you are already running an older version).
4. Optional: place the same JAR in each backend Paper/Spigot 1.16.5+ plugins/ folder for the Java inventory selector. Backend and proxy must run Java 17+.

plugins/
├── VelocityNavigator-4.3.0.jar
└── ...

On first start, VelocityNavigator generates navigator.toml for systems, messages.toml for language, gui.toml for Java/Bedrock menus, and servers.toml for command-managed lobbies. The universal JAR logs whether it started in proxy or backend bridge mode.

---

Step 2: Watch It Work with Defaults

Out of the box, VelocityNavigator uses:

• Selection mode: least_players (picks the server with the fewest players)
• Lobbies: placeholder entries named lobby-1 and lobby-2; edit navigator.toml to match registered Velocity servers
• Circuit breaker: enabled (automatically skips unhealthy servers)
• Health checks: enabled with a 60-second cache

If lobby-1 and lobby-2 are registered in velocity.toml, players typing /lobby are routed to the emptier one. Otherwise replace the placeholder names before relying on routing.

---

Step 3: Edit navigator.toml

Open plugins/velocitynavigator/navigator.toml and set your lobby server names:

[routing]
selection_mode = "least_players"
default_lobbies = ["lobby-1", "lobby-2", "lobby-3"]

Important: server names in default_lobbies must exactly match the server names defined in velocity.toml.

Save the file, then run /vn reload in the proxy console.

To change the server-wide language, edit only the language line at the top of messages.toml:

language = "ru"

Built-ins: en, ru, es, fr, de, pt_br, zh_cn. Any other value creates a custom-language workflow and preserves text for manual editing. Locale detection is intentionally disabled.

To enable the inventory selector:

[routing]
use_menu_for_lobby = true

[routing.java_menu]
type = "inventory"
fallback_to_chat = true

Install the same universal JAR on each backend, restart it, let a player join, and verify with /vn bridge status. Customize rows, materials, fixed slots, pagination controls, and refresh timing in gui.toml.

Before enabling advanced systems, run /vn config validate. For managed servers, use /vn server dry-run game ... or /vn server dry-run lobby ... before the real add command.

---

Step 4: Choose a Selection Mode

Not sure which algorithm to use? Follow this decision tree:

How many lobby servers do you have?
│
├─ 1–3 servers ──── least_players   (simple, always picks emptiest)
│
├─ 4–10 servers ─── power_of_two    (fast, near-optimal distribution)
│
├─ 10+ servers ──── least_connections (EMA-based, handles bursty traffic)
│
└─ Need sticky sessions?
   │
   ├─ Yes ──── consistent_hash  (players return to "their" server)
   │
   └─ Need weighted distribution?
      │
      └─ Yes ──── weighted_round_robin  (some servers get more traffic)

Mode	Summary
least_players	Picks the server with the fewest players. Suited to small networks.
power_of_two	Picks two at random and chooses the emptier one. Good default for medium networks.
round_robin	Strict rotation. Useful for testing.
random	Each player gets a random server. Performs well at scale.
weighted_round_robin	Round-robin where some servers receive more traffic than others.
least_connections	Tracks connection rate over time. Good for bursty traffic.
consistent_hash	Same player maps to the same server. Useful for session affinity.
latency	Selects the healthy candidate with the lowest measured ping. Useful when latency differs meaningfully between backends.

See Routing Algorithms for the full reference.

---

Step 5: Confirm the setup

1. Join your network.
2. Type /lobby.
3. You should be connected to one of your lobby servers.

Check the routing decision:

/vn debug player YourName

Verify distribution across your servers:

/vn status

---

Next Steps

• Configuration Guide — customize every setting
• Routing Algorithms — how each algorithm works
• Operations Runbook — drain servers, check health, troubleshoot

---

Total time: about 5 minutes. You are now running VelocityNavigator v4.3.

Optional advanced systems

VelocityNavigator 4.3.0 can also provide native parties, full-pool queues, Redis multi-proxy synchronization, dynamic backend registration, and MOTD lifecycle-state routing. Configure them in navigator.toml using the Advanced Proxy Systems guide.
