Modifiers

Modifiers

Modifier is the same idea as Compose's: a chain of things said about a widget, folded left to right, read by layout and by drawing.

Panel(Modifier.align(Alignment.BottomStart).padding(20f).width(280f)) { … }

If you know Modifier.padding(8f).background(Color.Blue), you know this. What follows is the list, and the three rules that are ours.

---

The list

Size

Modifier.size(64f)                 // square
Modifier.size(width = 200f, height = 40f)
Modifier.width(280f)
Modifier.height(40f)
Modifier.fillMaxWidth()            // all of what the parent offers
Modifier.fillMaxHeight(0.5f)       // half of it
Modifier.fillMaxSize()
Modifier.fillMaxWidth().aspectRatio(3f / 4f)  // as wide as the slot, height follows at 3:4
Modifier.widthIn(min = 200f, max = 400f)   // as wide as the contents, inside that range
Modifier.heightIn(min = 40f)
Modifier.sizeIn(minWidth = 64f, minHeight = 64f)
Modifier.defaultMinSize(minWidth = 48f)    // only when nothing else says a width
Modifier.width(IntrinsicSize.Max)  // as wide as the contents would like, asked first
Modifier.height(IntrinsicSize.Min) // as short as they can be squeezed to
Modifier.animateContentSize()      // grows to new contents rather than jumping

A range is a rule rather than a wish, so it holds wherever it sits in the chain: width and fillMaxWidth are measured inside it. See Layout for the details.

Growing with its contents. animateContentSize moved to Animation.

Space

Modifier.padding(12f)
Modifier.padding(horizontal = 16f, vertical = 8f)
Modifier.padding(left = 28f, bottom = 28f)
Modifier.paddingFrom(Baseline.First, before = 24f)  // measured to the text's line, not its box
Modifier.paddingFromBaseline(top = 28f, bottom = 12f)
Modifier.offset(x = 0f, y = 2f)    // move it, without moving anything else
Modifier.parallax(pointer, factor = -0.02f) // …by how far the pointer is from the middle

Parallax is cheap depth. Moved to Animation.

Where it goes

Modifier.align(Alignment.TopEnd)   // inside a Box
Modifier.weight(1f)                // inside a Row or Column
Modifier.zIndex(1f)                // drawn over its siblings, and clicked first
Modifier.layoutId("icon")          // inside a layout of your own; see [[Custom layouts]]
Modifier.worldPosition(120f, 80f)  // inside a PanZoomCanvas; see [[Widgets]]
Modifier.wrapContentSize()         // its own size, centred in a slot bigger than it
Modifier.wrapContentWidth(HorizontalAlignment.End)
Modifier.animatePlacement()        // slides to a new slot instead of jumping there

zIndex is for lifting one thing out of a pile. Siblings paint in the order they are written. A selected card, a dragged tile, a hovered item can come forward without being moved in the code — which would also move it in focus order and change what recomposition matches it by:

Card(Modifier.zIndex(if (selected) 1f else 0f))

Higher is drawn later, so on top. Equal values keep source order, so the default of zero changes nothing, and a negative value sinks a node under its siblings. Clicks and hover follow the picture: where two cards overlap, the one on top gets the press. Layout and focus do not — a row still lays out left to right as written, and Tab still walks in source order. It orders siblings only: a child with a huge zIndex inside a low parent stays under that parent's higher siblings. Two on one node add, like offset.

animatePlacement is for lists that change. Moved to Animation.

How it looks

Modifier.background(Colour.rgb(0x1A1F28), corner = 6f)
Modifier.background(Brush.vertical(top, bottom), corner = 6f)   // a gradient
Modifier.border(Colour.rgb(0x2C3545), width = 1f, corner = 6f)
Modifier.border(accent, width = 2f, style = BorderStyle.Dashed(on = 6f, off = 4f))
Modifier.border(accent, width = 2f, corner = 8f, style = BorderStyle.Dotted)
Modifier.border(bottom = BorderSide(1f, divider))   // one edge: a divider, a tab's underline
Modifier.shadow(Colour.argb(0x80000000), spread = 12f, corner = 6f)
Modifier.ninePatch(frame)          // skin art, stretched properly
Modifier.background(Accent, Corners.top(8f))  // …with a radius per corner
Modifier.clip()                    // children cannot draw outside
Modifier.clip(corner = 6f)         // …with rounded corners
Modifier.clipShape(Shapes.Circle)  // …or any convex shape: a round portrait
Modifier.alpha(0.4f)               // the subtree fades as one thing
Modifier.tint(Colour.Red)          // …every colour in it multiplied by red
Modifier.scale(1.2f)               // …drawn bigger, without re-laying it out
Modifier.mirror()                  // …flipped to face the other way
Modifier.rotate(8f)                // …turned clockwise
Modifier.skew(x = -12f)            // …slanted, top leaning forward
Modifier.rotate3d(y = 180f)        // …turned over in depth, like a card
Modifier.blur(radius = 8f)         // …through a shader, from composegl-effects

Clipping to a shape. clip() is a rectangle, and free. clipShape cuts to any convex shape instead — a round portrait, a diamond minimap, a hexagon tile — from square art, at draw time:

Image(portrait, Modifier.size(64f).clipShape(Shapes.Circle))
Box(Modifier.size(96f).clipShape(Shapes.Diamond)) { Minimap() }
Box(Modifier.clipShape(Shapes.polygon(0.5f, 0f, 1f, 1f, 0f, 1f))) { … }  // fractions of the box

The shapes are Shapes.Rectangle, Circle, Ellipse, Diamond, Hexagon, roundedRect(corner) and polygon(…). A polygon's points are fractions of the widget's box, so one shape fits every size; a concave one throws, because only a convex outline can be drawn in one piece.

Chain order decides what is cut. What the chain paints after clipShape is cut with the content and children; what it paints before stays whole:

Modifier.border(ring, 2f).clipShape(Shapes.Circle).background(grey)  // square ring, round disc

What the shape cuts away cannot be clicked either — the click goes to whatever is drawn there instead. The same shape goes to hitShape to make the widget itself round to the pointer without cutting anything:

Modifier.hitShape(Shapes.Circle)

A shaped clip draws the widget into an offscreen picture and puts it back through the shape, with an edge softened over one screen pixel. That is one picture per clipped widget per frame: fine for portraits and a row of tiles, not for a thousand. A canvas that cannot make or cut pictures clips to the rectangle instead.

Skew is for leaning. A banner with speed in it, an italic-style title card, the slanted bars of a fighting-game HUD:

Banner(Modifier.skew(x = -12f))                                   // top leans forward
HealthBar(Modifier.skew(x = -20f, origin = Alignment.BottomStart)) // bottom edge stays put
Ribbon(Modifier.skew(y = 8f))                                     // sides upright, sliding down

The angles are degrees, with the sign CSS uses: negative x puts the top to the right. It is built like scale and rotate — the widget is drawn upright into a picture and the picture is put down on four corners — so text inside is not asked for an oblique font and layout does not move. A skew and a rotate on the same widget share one picture. Clicks do not follow it: a slanted widget is hit inside its upright box, exactly as a turned one is. Two skews on one axis add their slopes, and an angle of ±90 or beyond throws. On a canvas that cannot put a picture on four corners (canvas.drawsLayersOnto) the widget is drawn without the slant.

Tint multiplies a whole subtree by a colour. A damage flash, a locked item dimmed, one piece of art in every team's colour — with no shader and no offscreen picture, just the multiply a tinted image already gets:

Hotbar(slots, Modifier.tint(Colour.Red.scaleAlpha(flash)))   // flash runs 1 → 0
Image("sword", Modifier.tint(Colour.Grey))                   // locked
Image("banner", Modifier.tint(team.colour))                  // one banner, four teams

Hotbar is a game widget from composegl-game (import dev.wildware.composegl.game); see Game widgets.

The colour's alpha is how strong the tint is, not an opacity: at 0 nothing changes, at 1 the colour applies in full. So a flash is one number animating back to zero. Fade with alpha, not with this.

Two tints multiply, on one widget or nested, so a team colour on a locked slot is both. White changes nothing and nothing gets brighter, so a flash towards white wants an additive overlay instead; turning something truly grey wants colourGrade. What a raw block draws is not tinted. A canvas says whether it can with canvas.tints; every backend here can.

Rotate3d is for depth. A card flipping over, a panel swinging in on its hinge, a menu tipping towards the pointer:

Card(Modifier.rotate3d(y = flip * 180f))                                   // turns over
Panel(Modifier.rotate3d(y = -70f * (1f - arrival), origin = Alignment.CentreStart)) // swings in
Menu(Modifier.rotate3d(x = -tilt.y * 8f, y = tilt.x * 8f))                 // leans at the pointer

Angles are degrees with CSS's signs: positive y sends the right edge away, positive x sends the top edge away, positive z turns clockwise like rotate. They are applied z, then y, then x, about origin, and a camera straight in front of that point looks at the result. cameraDistance is in 72-pixel inches, as on Android, so the default 8 puts it 576 pixels away; smaller is more dramatic.

It is built like rotate and skew: the widget is drawn flat into a picture, and the picture is put down through the camera. The GPU divides by depth for every pixel, so the picture does not bend along the diagonal. A skew and a rotate on the same widget share the picture. Past 90 degrees you see the back of the picture, mirrored — a two-sided card swaps what it composes at the halfway point:

val angle = flip * 180f
Card(Modifier.rotate3d(y = angle)) {
    if (angle < 90f) Front() else Back(Modifier.mirror())  // mirrored again, so it reads
}

Clicks do not follow it: a tilted widget is hit inside its flat box, like a turned one (hitShape is the escape hatch). Two rotate3ds add angle by angle. On a canvas that cannot tilt a picture (canvas.tiltsLayers) the widget is drawn without the depth.

Perspective gives a group one camera. On its own each tilted widget has a camera straight in front of its own middle, so five cards turned the same way are five identical shapes. Put perspective on their parent and they share one vanishing point, like cards on a table:

Row(Modifier.perspective(distance = 800f, origin = Alignment.Centre)) {
    cards.forEach { Card(Modifier.rotate3d(y = tilt)) }
}

The card left of the camera shows more of its face than the one to the right. The distance is in pixels, as in CSS's perspective, and origin is where on the parent the camera sits. Every rotate3d anywhere inside uses it, not only direct children, and it replaces their own cameraDistance; each card still turns about its own origin. A nearer perspective wins. A tilted widget flattens what is inside it, so a tilt inside a tilted card goes back to its own camera, unless that card has a perspective of its own. The parent itself is not tilted by it, and it costs no picture.

Scale is for arriving and for fitting. The widget and everything under it are drawn into an offscreen picture at the size layout gave them, and that picture is put down bigger or smaller:

Panel(Modifier.scale(spring.value)) { … }                  // a panel springing in
Panel(Modifier.scale(min(1f, budget / measured))) { … }     // one squeezed to fit
Panel(Modifier.scale(1.4f, Alignment.TopStart)) { … }       // grown from a corner

Layout does not move, so a panel arriving does not shove its neighbours and a fit correction does not re-flow what is inside it. Clicks and pad focus do move: boundsInRoot reports where the widget is drawn, so a button drawn at twice the size is clickable at twice the size. layoutBoundsInRoot is the rectangle before any scaling, for the code that wants the slot rather than the pixels. And paintedInRoot is a third question again — what the subtree actually painted, scaling folded in, which for text is the glyphs rather than the line box and for a bare Box used only for layout is nothing at all:

val ink = node.paintedInRoot          // null: it drew nothing, or has not been laid out

Reach for it when something has to frame composed content — a debug overlay, a focus ring that should hug the letters, a screenshot cropper, a containment assertion in a test. Using the node box for any of those over-reports by roughly the leading plus the descent: small enough to look like a rounding bug, big enough to fail a strict check.

To see all three on a running screen, turn on LayoutOverlay: blue for the laid-out box, yellow for where a scale draws it, pink for the ink. See Debugging.

A few things to know. It magnifies a picture, so past about 1.15 it is visibly soft and text is soft sooner — a world that wants to be crisp at three times the size wants to be laid out three times the size. The capture is the widget's own rectangle, so anything a child draws outside it is cut off while the scale is on — and clicks agree, so what you cannot see you cannot press. The other direction is not true: the picture is put down filling the scaled rectangle, so clip() on the same widget does not hold it in. A viewport that must not spill wants the clip on the parent and the scale on the child inside it.

A canvas can refuse to make the picture at all, and every backend here refuses one bigger than 4096 screen pixels a side. Then the subtree is drawn plainly, at its ordinary size, and hit testing goes back with it. Ask canvas.drawsLayers first if a screen would rather pick a different animation.

Two scales on one widget multiply, so an arrival animation and a fit correction compose. A scale of one takes no picture at all. Zero draws nothing and cannot be clicked or focused, which is what lets a panel arrive from nothing. A negative factor throws rather than mirroring — flipping is mirror(), below — so hand an anticipate easing over as scale(t.coerceAtLeast(0f)).

Mirror is for one piece of art facing either way. The same offscreen picture, put down read from the other side, flipped in place about the widget's middle:

Portrait(Modifier.mirror(horizontal = speaker.isOnRight))   // a speaker on either side
Arrow(Modifier.mirror(vertical = pointsDown))               // one arrow, up or down

Text inside flips too, and reads backwards — nothing inside knows it is being mirrored. Mirror the art, and put the name label beside it rather than inside it.

Layout does not move. What is inside does, and clicks, pad focus and boundsInRoot move with it: in a mirrored row the first child is drawn on the right, clicked on the right, and is where focus goes when the player presses right. A pointer handler inside gets its own coordinates mirrored too, so a drag to the right on screen is a drag to the left to it — which is what keeps a mirrored slider under the finger. The same goes for the arrows and the pad a focused widget claims: pressing right on a mirrored slider moves its knob right on screen, which is towards its own minimum.

Two mirrors cancel, so a flipped portrait inside a flipped panel faces the way it was drawn. mirror(horizontal = false) takes no picture, so the flag can come straight from game state. It shares a picture with a scale on the same widget, and is flipped first and then turned under a rotate. The rest is scale's bargain: the capture is a clip, and a canvas that cannot flip a picture (canvas.mirrorsLayers) draws the widget the right way round and is clicked the right way round.

Shake

Moved to Animation.

Marquee

Moved to Animation.

Your own drawing

Modifier.drawBehind { bounds -> rect(bounds, Colour.rgb(0xE5484D)) }
Modifier.drawInFront { bounds -> border(bounds, Colour.White, 1f) }

The receiver is a UiCanvas and the argument is the widget's rectangle in screen coordinates.

Turning a picture, and making it glow. Two things the canvas can do that a plain rectangle cannot:

Modifier.drawBehind { bounds ->
    // A sunburst: one picture per ray, each turned about the hub on the left edge.
    pushBlend(BlendMode.Additive)        // light adds; paint covers
    repeat(14) { ray ->
        image(spark, bounds, degrees = ray * 360f / 14f, pivotX = 0f)
    }
    popBlend()
}

degrees turns clockwise, because y grows downwards here. destination is the box before turning, so the pixels can land outside it. The rays batch together — no draw call per ray — but a blend mode is a batch boundary, so push it round the whole group rather than per call: a dozen quads between one push and one pop cost two boundaries, not twenty-four. To find the nodes that do cut a batch on a running screen, see where the draw calls go.

Both degrade honestly on a backend that cannot do them: the picture is drawn upright and the glow is drawn as ordinary paint. Ask canvas.rotatesImages and canvas.supports(BlendMode.Additive) first if you would rather draw something else.

Seeing where a widget went

Panel(Modifier.debugBounds())                           // a magenta box round it
Panel(Modifier.debugBounds(Colour.Red, label = true))   // …with its size, 120x40, in the corner

What to write instead of a temporary border you then have to remember to take off. It draws an outline and a faint wash over the widget and its children, and changes nothing else: not the size, not the padding, not the clicks — a click goes straight through it. It is a data class, so a screen that recomposes with the same box on it stays still.

It paints where it sits in the chain, like a border. First, which is where a widget's own modifier puts it, boxes the whole widget; after a padding it boxes what the padding left. A widget laid out with no width shows as a line, which is often the answer. The label's digits are drawn with rectangles, so they need no font and look the same on every backend.

For every widget on the screen at once — boxes, padding and the gaps between children — use LayoutOverlay instead (Debugging). To point at one widget and read its size, the room it was given and its modifier chain, wrap the screen in Inspector (Debugging). To see which parts of the screen are painted over and over — stacked translucent panels, a scrim over everything — use OverdrawOverlay (Debugging).

A note on colours. Colour.rgb(0x…) and Colour.argb(0x…) are how you write one. There are also about a dozen named ones — Colour.Red, Colour.Grey, Colour.Orange — for a debug box, an example, or a prototype nobody has skinned yet. They are deliberately plain and deliberately few: your game's actual colours belong in its skin, where one edit changes every panel at once.

Input

Modifier.clickable { fire() }
Modifier.clickable(enabled = false) { }   // still swallows the click
Modifier.clickable(onDoubleClick = { equip() }, onLongPress = { actions() }) { select() }
Modifier.repeatingClickable { count++ }   // the + on a quantity picker
Modifier.interaction(state)               // hover and press, for drawing
Modifier.draggable { delta -> at += delta } // slop, capture and cancel done for you
Modifier.dragSource(payload = item) { ItemIcon(item) } // inside a DragAndDropHost
Modifier.dropTarget<Item>(accepts = { it.fits(slot) }, onDrop = { move(it, slot) })
Modifier.onActivate { pickUp(); true }    // South or Enter, before the click
Modifier.onPointer(handler)               // raw pointer events
Modifier.watchPointer(watcher)            // the same events, in front of nothing
Modifier.onKeyEvent(handler)
Modifier.onTextEvent(handler)
Modifier.hitShape { it.x >= 20f }         // which points inside the box are really yours
Modifier.pointerHoverIcon(PointerIcon.Hand) // the mouse cursor's shape over it

A note on watchPointer. A full-screen layer with onPointer on it is the topmost thing the pointer finds, so everything under it stops being hovered — even when the handler consumes nothing. That is right for a scrim over a dialogue and wrong for a layer that only wants to know where the mouse is: an item card hanging beside the cursor, a cursor a game draws itself. watchPointer is the other half of the pair. The node is found and told exactly what a handler would be told, but it is never hovered, never pressed and cannot consume, so the bag slot underneath lights up as if the layer were not there. Capture does not apply either: a press the slot takes, the moves while it is dragging and the release that ends it are all still reported, and so is the Exit when the mouse leaves the window.

A note on hitShape. Hit testing is rectangles, because nearly everything is a rectangle and rectangles are cheap. A round button, a diamond or a honeycomb cell is not, and its rectangle overlaps its neighbours' — so the empty corner of one sits over the middle of another and the click goes to whichever was drawn later. hitShape is how a widget says those corners are not its own; saying no lets the click carry on to whatever is underneath.

The question is asked in the widget's own coordinates, the ones onPointer delivers, with any scale already divided back out — so the shape is written once against the widget's own width and height and keeps working while it grows. Unlike clip it gates that one widget and says nothing about its children: it does not change what is drawn, so it must not change what is reachable. A child that wants the same shape asks for it itself. Two on one widget is a choice rather than a quantity, so the later one wins.

Focus

Modifier.focusable()
Modifier.focusRequester(requester)        // send focus straight here
Modifier.focusOrder(down = inventoryTab)  // override the geometry
Modifier.focusTrap()                      // a dialogue keeps focus inside itself
Modifier.onFocusWithin { inside -> … }
Modifier.onReveal { child -> scrollTo(child) }

Focus has its own page: Input.

Testing

Modifier.testTag("play")                  // host.root.find("play") from a test

Changes nothing about how the node looks or behaves. See Testing.

Being told where it ended up

Modifier.onPlaced { node -> anchor = node.boundsInRoot }   // it moved on screen
Modifier.onSizeChanged { size -> emitter.resize(size) }    // it got bigger or smaller

A popup under a button, a particle emitter the size of a panel, a tutorial arrow pointing at something: all of them need to know where a widget is, and none of them should ask every frame.

Both are called after layout has finished, so every rectangle in the tree is this frame's, parents first. Both are called only when the answer changed — the first layout counts — so a still screen calls nothing. onPlaced is about where the widget is drawn: a parent moving it or scaling it counts, even though the widget itself did not change. onSizeChanged is only its size, so moving is not resizing.

onPlaced hands you the node rather than a rectangle, because you usually want one of three: boundsInRoot for the pixels, layoutBoundsInRoot for the slot, or paintedInRoot for the ink. Read what you need during the call; do not keep the node.

State written in either lands on the next frame, the same as in Compose:

Rule 2 below applies: remember the handler on a widget that recomposes often.

---

The decoration ones, on the same box:

One radius, or one per corner. background (a colour or a gradient), border and shadow take a single corner, or a Corners with a radius for each — clockwise from the top-left, like CSS. That is how a tab rounds only along its top, a speech bubble keeps one sharp corner, and a panel docked to the edge of the screen stays square against it:

val speech = Corners(topLeft = 14f, topRight = 14f, bottomRight = 14f, bottomLeft = 0f)

Modifier.background(Accent, Corners.top(8f))                       // a tab
Modifier.shadow(Glow, spread = 10f, corners = speech)
    .background(Steel, speech)
    .border(Accent, width = 2f, corners = speech)                  // a bubble
Modifier.background(Steel, Corners.left(16f))                      // docked to the right edge

Give the border and the shadow the same Corners as the background, or they show at the corner that differs. Corners.top, bottom, left and right round two; Corners.all(r) is exactly corner = r. A backend that cannot round corners one by one draws every corner at the smallest of the four and says so through canvas.roundsCornersSeparately; every backend here can. clip(corners) rounds a clip the same way, through clipShape (see Clipping to a shape above).

Gradients: a Brush in place of a colour.

Brush.vertical(top, bottom)
Brush.horizontal(left, right)
Brush.linear(start, end, degrees = 45f)      // clockwise from pointing right
Brush.radial(centre, edge)                   // an ellipse that fits the box

Two colours each. The gradient runs edge to edge across the node, whatever its size, and a corner cuts it like any other fill — Modifier.background(brush, Corners.top(8f)) gives each corner its own radius. Fading to Colour.Transparent keeps the colour rather than darkening on the way. A backend without gradients draws the first colour flat; canvas.drawsGradients says which you have.

Borders can be one-sided, dashed or dotted. BorderSide(width, colour, style) is one edge, and Modifier.border(left =, top =, right =, bottom =) takes any of the four; a side left out is not drawn. The edges meet in square corners, top and bottom running the full width. A rounded outline is the all-sides border, where one line follows the curve.

BorderStyle.Dashed(on, off) stretches its lengths a touch so a whole number of dashes fits, which is why an edge always starts and ends on a dash. BorderStyle.Dotted is square dots as long as the line is thick, the same distance apart. Both are drawn as plain rectangles and lines, so every backend gets them without doing anything.

And what padding does to what is inside it:

---

Rule 1: order matters, and it is visible

Modifier.padding(8f).background(blue)   // blue is painted inside the padding
Modifier.background(blue).padding(8f)   // blue is painted across the whole widget

Both are useful and the difference is on the screen, which is why the chain stays in order rather than being collected into a bag of properties.

The same applies to two backgrounds, a background and a border, or a nine-patch and padding — each one paints where it sits in the chain.

---

Rule 2: equality is what makes a still screen free

A node's modifier is compared on every recomposition to decide whether anything changed. Every element is a data class, so the chain compares by value, and a screen that has not changed costs nothing.

The one thing that defeats that is a lambda written inline:

Modifier.drawBehind { … }        // ❌ a new object every recomposition

Same trap as Compose, same fix:

val glow = remember { drawGlow() }
Modifier.drawBehind(glow)        // ✅ compares equal

It only matters on a widget that recomposes often. clickable { } on a menu button is fine.

---

Rule 3: styled is how a widget gets its look

Box(Modifier.styled(style)) { … }

One call, because the three parts have to happen in order: the background paints across the widget, the padding keeps its contents off the edge, and the content offset moves those contents without moving the background — which is how a pressed button's label shifts down a pixel while its frame stays put.

A widget that writes styled(style) and then draws its text in style.textColour contains no colour, no corner radius and no texture name of its own. That is what makes one skin file change the look of a whole game. See Skins.

---

Writing your own

A modifier is an element plus an extension function:

data class GlowElement(val amount: Float) : Modifier.Element

fun Modifier.glow(amount: Float) = then(GlowElement(amount))

A data class, so the chain still compares by value. Then read it wherever it is meant to act — a measure policy, a draw pass, your own widget. The built-in ones are read by ResolvedModifier, which folds the chain once per node per frame.

---

What next

• Layout — size, weight, arrangement, alignment
• Skins — where styled gets its style from
• Input — clickable, focus, and what the handlers see
• Shaders — what effect can be given
• Animation — shake, marquee, parallax, and the rest of what moves
