Execution Print

Execution Print — Modernized Screen

Modernization of the legacy Execution Print popup (lib/execute/execPrint.php), which renders a printable document for a single execution row: the linked test-case definition (summary, author, importance, preconditions, steps with execution results/notes, custom fields, keywords, requirements), overall execution status, build, tester, dates and the direct-linked public execution URL. GitHub issue #844.

Replaced by a standalone Dashio page gui/templates/execute/execPrint.html backed by a plain-PHP REST BFF API api/executionprint/index.php.

Path: Execute Tests (execTest.html) or Execution History (execHistory.html) → execution row → Print → popup. URL: gui/templates/execute/execPrint.html?id=<execution_id> BFF API:

• GET ?action=print&id=N → { status, exec_id, page_title, body_html, meta{status, execution_ts, build_name, tester, tproject_id, tplan_id} }
• POST ?action=delete_attachment&id=N&deleteAttachmentID=M → { status, deleted, exec_id } (destructive action — POST only, same-origin-guarded; ownership-checked against the execution's own attachment list)

Rights: authenticated session + testplan_execute on the owning test project (403 otherwise); unknown / forged execution id → 404 (probed before render, no E_WARNING events).

---

Behavioral parity with the legacy controller

• Print body — generated server-side by lib/functions/print.inc.php renderExecutionForPrinting() (the exact function execPrint.php called): test-case header table, author/date, summary, preconditions, step table with execution-notes + execution-status columns, execution type/duration, execution notes, and the Direct Link: share URL. setPaths() guarantees $_SESSION['basehref'] for the renderer.
• Meta line — status badge (passed/failed/blocked/not-run), build name, tester, timestamp above the print body.
• Print — toolbar Print → window.print(); print CSS hides header/toolbar/footer.
• Attachment delete — the legacy render embeds an inline <form> per execution-step attachment (POST deleteAttachmentID to execPrint.php). The modern screen intercepts the submit in JS and routes it through the BFF delete_attachment route, then re-renders.

Security hardening (intentional, Refs #844)

Legacy execPrint.php opened testlinkInitPage($db,false,true) — callable without a session for the external-direct-link use case. The modern screen runs inside the authenticated app, so the BFF requires a session user + testplan_execute. The public anonymous share link (lnl.php) intentionally keeps using legacy execPrint.php.

---

Screenshots

Normal execution print (admin, passed execution)

---

Test coverage

Test suite 844 (12/12 PASS) in tmp/TLU_Test_Cases.md — BFF print OK (200 + body), 404 unknown execution, 400 missing id, 403 no-rights, front-end render + 404/403 banners, Print handler, delete_attachment guards, i18n in all 10 bundles, in-app link switch, Event Viewer clean.
