Install Upgrade Modernized

Install / Upgrade Check — Modernized Screen

The Install / Upgrade screen reports the installation & schema status of a running TestLink instance. It replaces the legacy upgrade landing (install/index.php check flow + lib/functions/configCheck.php checkSchemaVersion() / checkForInstallDir() / checkForAdminDefaultPwd() messages) with a modern Dashio-styled page backed by a plain-PHP REST BFF.

Path: ASIDE menu → System → Install / Upgrade URL: gui/templates/install/installView.html BFF API: api/install/index.php — GET / (status JSON) Rights: any authenticated user (BFF returns 401 otherwise); ASIDE entry shown to users with the system_configuration global right Tracking issue: #797

Scope note: only the status-check part of the legacy install area is modernized. The full install wizard (install/index.php + step scripts) runs before the DB/session exist and intentionally stays legacy.

---

1. Overview

The screen shows, at a glance:

Status card	Content
App version	TL_VERSION (e.g. 2.0.1 [TEST])
Latest DB schema version	TL_LATEST_DB_VERSION (e.g. DB 2.0.0)
DB schema version	current value from the db_version table (max upgrade_ts)
Schema state	badge: OK / Upgrade needed / Manual upgrade / Unknown / Undetermined
Config file present	config_db.inc.php exists on disk
Database reachable	DB connection succeeded
GD library (charts)	gd extension + PNG support

Plus two panels: Upgrade Required (only when the schema is out of date — same message cases as the legacy checkSchemaVersion()) and Security Notes (install dir still present, default admin password, missing LDAP extension).

2. Schema-state logic (parity with legacy checkSchemaVersion())

DB version	Status	Client message key
TL_LATEST_DB_VERSION	ok	—
1.7.0 … , DB 1.1, DB 1.2	upgrade	install.msgUpgrade
DB 1.3 … DB 1.9.19	manual	install.msgManual
DB 1.9.20 + still-32-char password column	upgrade	install.msgPartialMigration
anything else	unknown	install.msgUnknown (shows schema + target version)
no DB / no row	undetermined	install.msgUndetermined

3. Actions

Action	Target
Open installer wizard	legacy install/index.php (full wizard, _top)
Installation manual	docs/testlink_installation_manual.pdf
README	repo root README
CHANGELOG	repo root CHANGELOG
Forum	http://forum.testlink.org — BFF links.forum (#1285)

4. Data flow

Step	Description
1	Screen boots TLi18n, renders header/toolbar
2	$.getJSON('/api/install/index.php') fetches status
3	BFF: session check (401), then version/schema/DB/security checks
4	Client renders status cards, badge, upgrade + security panels
5	Refresh re-fetches from BFF; locale switcher re-labels the page

5. Files

File	Purpose
gui/templates/install/installView.html	Dashio HTML screen
api/install/index.php	BFF API (install/upgrade status)
gui/templates/i18n/*.json (10 bundles)	i18n keys (install.*)
lib/functions/common.php	$actions->installView ASIDE link
gui/templates/dashio/aside.tpl	System → Install / Upgrade entry
gui/templates/dashio/labels/labels.aside.tpl	Smarty install_header label
locale/en_GB/strings.txt, locale/ro_RO/strings.txt	$TLS_install_header
lib/functions/configCheck.php	upgrade-linked message now points to the new screen
lib/functions/common.php, lib/general/mainPage.php	corrected legacy system_configuration right typo

6. Regression suite

See tmp/TLU_Test_Cases.md — Suite 797 — Install/Upgrade status screen (#797).

7. Community videos (contributor walkthroughs) — #1286

The legacy install landing page (install/index.php:52-58) carried a curated block, "Some user contributed videos (You Tube)", with four walkthroughs contributed by TestLink users. That block was dropped during modernization — the screen had no videos section and the BFF had no data source for it. It is now ported back.

7.1 What the screen shows

A third section, Community Videos, after Actions (the legacy order had the video block right above the "New installation" call to action):

#	Caption	Video
1	Installation of "TestLink" & Creating project	NOvTWZvc2x8
2	TestLink Test Management Tool Tutorial	P2zWScVjuag
3	Introduction to TestLink	7xH1LKQU1TA
4	TestLink Walkthrough	6s48WGuX2WE

Each card is an <a> with a dark play-button tile, the localized caption and a "YouTube" source line, styled like the other Dashio cards (white, 0 1px 4px shadow, red left border, teal on hover).

7.2 How it works

Step	Description
1	install_community_videos() in api/install/index.php returns the four {id, key, url} entries — the server-side single source of truth
2	They are exposed as the top-level JSON key videos, next to the existing links object
3	renderVideos(r) in installView.html renders #videos; #videosSection / #videosHint stay hidden until the payload has entries

The caption is not hardcoded in the HTML: the BFF sends an i18n key per video (install.videoInstallProject, install.videoTestManagementTool, install.videoIntroduction, install.videoWalkthrough) and the client resolves it with TLi18n.t(), so the block is localized in all 10 bundles like every other label.

7.3 Deliberate deviations from legacy

Legacy	2.0.1	Why
<a … target="#">	target="_blank" rel="noopener noreferrer"	target="#" was a no-op that also handed window.opener to YouTube
titles inline in the PHP file	i18n keys + 10 bundles	mandatory i18n (rule 3)
plain <a> + <br> list	Dashio card grid, responsive	look & feel (rule 5)
no guard	non-https URLs, entries without url, and null entries are dropped; empty list hides the section	the screen must not render a hostile href or an empty shell

7.4 Files

File	Purpose
api/install/index.php	install_community_videos() + the videos JSON key
gui/templates/install/installView.html	.videos/.video-card CSS, the #videosSection/#videosHint/#videos markup, renderVideos()
gui/templates/i18n/*.json (10 bundles)	install.videosTitle, install.videosHint, install.videoSource + the 4 caption keys

7.5 Regression suite

See tmp/TLU_Test_Cases.md — Task — Issue #1286 (8 cases, all PASS): payload parity with legacy, 4 rendered cards, target/rel, ro localization, 10-bundle i18n completeness, degenerate/hostile payloads, console + Event Viewer clean.

8. Community forum link — #1285

8.1 What legacy did

The legacy installer landing page offered the TestLink community forum twice (install/index.php:25 defines $forum_url = 'forum.testlink.org'):

• inline in the migration notice — :45 "Please read Section on README file or go to http://forum.testlink.org (Forum: TestLink 1.9.4 and greater News,changes, etc)"
• as a standalone link beside the manual / README / CHANGELOG links — :49-50 "You are welcome to visit our forum to browse or discuss."

Modernization ported the doc links but not the forum, so the Actions box offered four buttons and the migration notice said nothing about the forum.

8.2 What the modern screen does now

• api/install/index.php serves 'forum' => 'http://forum.testlink.org' in the links payload — the URL lives server-side, the front-end never hardcodes it.
• renderActions() appends a 5th action button Forum (fa-comments, .action-btn blue) after CHANGELOG, mirroring legacy :49-50. Rendered only when links.forum is a well-formed http(s) URL (regex allow-list, same defensive pattern as renderVideos()), so an older BFF payload or a malformed value degrades to the previous four buttons instead of a dead or javascript: link.
• renderForumNotice() writes the forum sentence into #upgradeForum inside the upgrade panel — shown exactly when a schema migration is pending, the modern equivalent of the legacy :45 notice sentence, and hidden again when the schema is up to date.
• Both anchors are built with jQuery .attr() (no concatenated HTML), restricted to http(s) by that allow-list, carry target="_blank" rel="noopener noreferrer" and expose the URL as title. The notice is cleared again when the schema returns to OK (no stale markup).
• The rendered notice reads Forum (TestLink 1.9.4 and greater - news, changes, etc.) — the hint deliberately does not repeat the label, matching legacy :45 where the anchor and the parenthetical were two different things.
• i18n: install.forum and install.forumHint in all 10 bundles (+2 lines each).

8.3 Files

File	Purpose
api/install/index.php	links.forum in the status payload
gui/templates/install/installView.html	renderForumNotice(), #upgradeForum markup, the Forum action button
gui/templates/i18n/*.json (10 bundles)	install.forum, install.forumHint

8.4 Regression suite

See tmp/TLU_Test_Cases.md — Task — Issue #1285 (9 cases + a 7-case post-review hardening addendum, all PASS): button rendered, href/target/rel, links.forum in the BFF payload, forum sentence inside the upgrade panel (hidden again when the schema is OK), localisation in ro/ja/en, 10-bundle key completeness, attribute-injection and javascript:-URL probes rejected by the allow-list, stale-notice cleanup, node --check / php -l / console / Event Viewer clean.

9. Attachments-repository (FS) security check — #1283

9.1 The gap

Legacy getSecurityNotes() (lib/functions/configCheck.php:250-300) ended with the attachments repository check (:275-282):

if ($repository['type'] == TL_REPOSITORY_TYPE_FS) {
  $ret = checkForRepositoryDir($repository['path']);
  if (!$ret['status_ok']) { $securityNotes[] = $ret['msg']; }
}

checkForRepositoryDir() (:368-390) is a is_dir() + is_writable() test that composes the note out of localized fragments: directory for attachments: <path> does not exist / … exists The directory is not writable!. The note was displayed by the legacy login page (login.php:230) and by the main page (lib/functions/common.php:1853-1858, gated by config_get('config_check_warning_frequence')), so the gap of this issue is scoped to the modernized Install / Upgrade screen, which had no equivalent check at all.

Modernization ported the install-dir / LDAP / default-admin-password / e-mail-config notes into api/install/index.php, but never the FS branch — an installation whose attachments directory was missing or read-only showed no warning on the Install / Upgrade screen, although every attachment upload would fail.

9.2 What the modern screen does now

• install_check_repository_dir() in api/install/index.php mirrors configCheck.php:368-390 line by line (same lang_get() fragments, same clearstatcache() / is_dir() / is_writable() logic) and additionally returns exists / writable for the front-end badge.
• It runs only when config_get('repositoryType') == TL_REPOSITORY_TYPE_FS, exactly like legacy. The result is published as a top-level repository block: {type, typeCode, path, checked, status_ok, exists, writable, msg}.
• On failure the legacy string is appended to securityNotes (unchanged wording, so any other consumer of the payload sees the legacy text) and the code repository_dir to securityCodes.
• securityNoteItems — a new array parallel to securityNotes — carries {code, key, params} for the notes whose text must follow the UI language (here install.repoDirMissing / install.repoDirNotWritable with {path}), null for every pre-existing note, which keeps their current server-rendered strings. installView.html re-composes the note with TLi18n.t(key, params) and falls back to the server string if the key is missing.
• Two ATTACHMENTS REPOSITORY cards in the Installation Status grid: the repository type (Filesystem / Database) and the directory state badge — green repoDirOk, red repoDirNotWritable / repoDirMissing, and an explicit repoDirNotChecked state for the DB type (legacy evaluates the directory only for FS). Values are injected with esc() and the badge class comes from a fixed allow-list, so a path can never inject markup.
• i18n: install.repository, install.repoTypeFs, install.repoTypeDb, install.repoDirOk, install.repoDirMissing, install.repoDirNotWritable, install.repoDirNotChecked in all 10 locale bundles (+7 lines each).

Reproduce a failing state without editing the repository: the built-in server honours TESTLINK_UPLOAD_AREA (config.inc.php:1615-1619), e.g. TESTLINK_UPLOAD_AREA=/tmp/tlu_missing_dir_test php -S 127.0.0.1:8082 -t . with that directory chmod 555, or a non-existent path.

9.3 Files

File	Purpose
api/install/index.php	install_check_repository_dir(), repository block, repository_dir note, securityNoteItems
gui/templates/install/installView.html	renderRepositoryCards(), localized security-note rendering
gui/templates/i18n/*.json (10 bundles)	install.repository, install.repoType*, install.repoDir*

9.4 Regression suite

See tmp/TLU_Test_Cases.md — Task — Issue #1283 (7/7 PASS): healthy FS dir (green badge, no note), not-writable dir, missing dir, healthy-state regression, ro localisation, DB type (no check), Event Viewer / console / php -l / node --check / json.tool gates.

10. Bug Tracking System connection security check — #1282

10.1 The gap

Legacy getSecurityNotes() (lib/functions/configCheck.php:251-330) — rendered by login.php:230, lib/functions/common.php:1787 and mainPage.php:184 — checked the Bug Tracking System connectivity right after the install-dir / LDAP / default-password notes:

// configCheck.php:273-275 (inside getSecurityNotes())
if (!checkForBTSConnection()) {
  $securityNotes[] = lang_get("bts_connection_problems");
}

// configCheck.php:340-350
function checkForBTSConnection()
{
  global $g_bugInterface;
  $status_ok = true;
  if($g_bugInterface && !$g_bugInterface->connect()) { $status_ok = false; }
  return $status_ok;
}

The gated string ships in every locale (locale/en_US/strings.txt:2582-2584): "Connection to your Bug Tracking System has failed … Be careful this problem will degrade TestLink performance."

api/install/index.php had ported only the install-dir, LDAP / default-admin-password, e-mail-config and attachments-repository checks, so an installation whose Bug Tracking System was unreachable showed no warning at all on the Install / Upgrade screen — exactly the degradation legacy warned about.

10.2 What the modern screen does now

• install_check_bts_connection($db) in api/install/index.php ports checkForBTSConnection(). The subtlety is the scope: $g_bugInterface is project-scoped (built by tlIssueTracker::getInterfaceObject($tprojectID), tlIssueTracker.class.php:745-786), and the Install / Upgrade screen has no test-project context, so there is no literal $g_bugInterface to test. The faithful analog is every tracker linked to at least one test project — precisely the contexts in which legacy would have had a non-null $g_bugInterface. A tracker configured but linked to no project can never be anybody's active BTS, so it is skipped (no false positive, and no pointless outbound connect on every page load).
• The check calls connect(), not isConnected() — legacy semantics: connect() is what actually opens the DB / SOAP / REST / socket handle, isConnected() only reports a cached flag.
• Instantiation follows the established pattern of api/issuetracker/index.php:212-243 (getByID()['implementation'] + new $impl(...) inside try/catch (\Throwable) with a class_exists() probe), NOT tlIssueTracker::getInterfaceObject(), which only catches Exception and echos raw HTML on failure (tlIssueTracker.class.php:781-784) — that would corrupt the JSON response. An unknown/unloadable implementation (issues #1617 / #1635) degrades to "connection failed" instead of a 0-byte 500.
• A top-level bts block publishes {checked, configured, linked, failed[], status_ok}: configured = rows in issuetrackers, linked = distinct trackers joined with testproject_issuetracker (DISTINCT: 3 projects on one tracker connect it once), failed = the names that could not connect.
• On failure the legacy string is appended to securityNotes (unchanged wording) with the code bts_connection, and securityNoteItems carries {code, key: install.btsConnectionProblems, params: {trackers}} so the front-end can name the failing trackers and follow the active UI language. The note is inserted before the repository note, matching legacy getSecurityNotes() ordering (:273-275 before :275-282).
• i18n: install.btsConnectionProblems with a {trackers} placeholder, in all 10 locale bundles (+1 line each).

Reproduce a failing state without a real bug tracker: insert an issuetrackers row of type 2 (bugzilla/db) whose cfg has no <dbhost>, and link it to a test project through testproject_issuetracker. issueTrackerInterface::connect() then returns false — the legacy symptom. Type 24 (mantis/rest, the session double from #1560) is the reachable control.

10.3 Two defects fixed on the way

1. issueTrackerInterface::connect() logged an E_WARNING per check on PHP 8. is_null($this->cfg->dbhost) runs on a stdClass produced by json_decode() of the tracker cfg XML (setCfg(), :165); a cfg that omits <dbhost> leaves the property absent, and is_null() on an absent property raises "Undefined property: stdClass::$dbhost" (issueTrackerInterface.class.php:202) before it can answer — 6 events rows measured while verifying this issue. Replaced with the exactly equivalent !isset($this->cfg->dbhost) || !isset($this->cfg->dbuser) (isset() is true for neither a missing nor a null property, so the return value is unchanged). This also de-noises the pre-existing api/issuetracker/index.php connection checks, which had the same latent hazard.
2. securityCodes was shorter than securityNotes. The four e-mail-config notes pushed no code, so any API consumer zipping the two arrays attached every code to the wrong note (measured: notes=8 codes=5, the bts_connection code landed on an e-mail parameter). The four notes now push email_config, and — like securityNoteItems — $securityCodes is padded with 'unknown' if the two arrays ever drift again.

10.4 Front-end hardening

gui/templates/install/installView.html needed no structural change (the generic securityNoteItems renderer already handles any keyed note), but two robustness fixes landed in the same loop:

• an empty localized string now falls back to the server string instead of producing a blank bullet (the guard used to sit inside the .text() argument);
• the server-side fallback is a legacy multi-line message containing literal <br /> tags. The <li> is filled with .text() to stay XSS-safe, so those tags were displayed verbatim; they are now converted into real line breaks (white-space: pre-line), still through .text(), so no HTML is ever injected from the BFF.

10.5 Files

File	Purpose
api/install/index.php	install_check_bts_connection(), bts block, bts_connection note, securityCodes alignment
lib/issuetrackerintegration/issueTrackerInterface.class.php	isset() guard in connect() (no more E_WARNING)
gui/templates/install/installView.html	localized note rendering, safe <br> fallback
gui/templates/i18n/*.json (10 bundles)	install.btsConnectionProblems
docs/screenshots/issue-1282-bts-connection-note.png	Security Notes panel with the BTS warning (en)
docs/screenshots/issue-1282-bts-note-ro.png	same note localized to Romanian

10.6 Regression suite

See tmp/TLU_Test_Cases.md — Task — Issue #1282 (11/11 PASS): no tracker, tracker not linked, reachable tracker, unreachable tracker, unknown tracker type, DISTINCT linking, browser rendering (en + ro), Event Viewer (0 Error/Warning rows), syntax/JSON gates and legacy-wording parity.
